Anzhong Building Materials is headquartered in Shanghai; The company's fixed assets exceed 60 million yuan. It has branches, warehouses and production bases in Beijing and Hebei; Each production base has advanced automated production lines. Its strong technical force, unified management system, unified technical standards, unified testing procedures, advanced testing equipment, and the selected copying technology and European advanced surface treatment technology ensure the excellent quality of products and enjoy a good reputation in the market, The test results of its products meet the national standards.
On the basis of high-density fiber cement floor boards, Anzhong Floorslab is a new generation of floor boards developed and produced by formula and production technology.
Floor King is a new floor developed on the basis of attic board and partition board, using auxiliary materials and formula, and is a replacement product of domestic high-density fiber cement floor boards at present; The defects of the original product, such as easy bending and deformation, easy water absorption and expansion, and easy layering, are solved.
1. Higher strength
2. Lower moisture rate
3. Stronger impact resistance
4. Higher bearing capacity
5. More secure
Application scope of Anzhong floor slab king
1. Steel structure interlayer
2. Loft loft
3. Warehouse compartment
4. Plant compartment
5. Duplex building
6. Booth
7. Floor
8. Stairs
9. Activity room
Spacing relationship between common thickness of floor slab king and steel structure:
1. 15mm floor slab king: steel beam spacing 400 * 400mm
2. 18mm floor slab king: steel beam spacing 488 * 488mm
3. 20mm floor slab king: steel beam spacing 600 * 600mm
4. 24mm floor slab king: steel beam spacing 1200 * 600mm
5. 30mm floor slab king: steel beam spacing 1200 * 600mm
Recommended steel beam of floor slab king
1. Span within 8m: 15H section steel for main beam, 10 channel steel for secondary beam and 63 angle steel for secondary beam.
2. The distance between beams refers to the distance from the outer edge of the edge beam to the center of the inner beam and from the center of the inner beam to the center of the inner beam.
3. No embedded parts shall be fixed with expansion bolts.
4. The upper and lower beam structure can be used if the space is sufficient, and the plane structure can be used if the space is insufficient.
Welding requirements for steel structures
1. At least three sides shall be welded, and the top surface may not be welded.
2. The weld strength and welding quality must meet the requirements of GB/T5185-1985 and GB/T985-1988 standards.
3. If the plate edge is in the suspended position, secondary beams must be added.
Installation of floor slab king
1. Before laying the plate, the weld on the top surface must be polished flat, and the welding spatter must be cleaned.
2. The longitudinal direction of the slab shall be parallel to the main beam.
3. No edge of the slab shall be suspended.
4. 3-5mm gap shall be left between plates.
5. The joints between plates shall be located at the center of the beam.
Nailing requirements of floor slab king
1. The length of self tapping screw shall be 55-60mm.
2. Drill holes before nailing, and the nail hole shall be larger than the diameter of the nail.
3. The nailing starts from the nail in the center of the board, and then goes out to drive edge nails.
4. The nailing position of edge nails shall be about 20mm away from the edge of the board.
5. The nail pitch is 300-600mm.
6. The side close to the wall may not be nailed.
Treatment of floor slab king joint
1. When laying boards, 3-5mm gaps must be left between boards and between boards and walls (if no gaps are left when laying wood floors).
2. The joints can be filled with silicone sealant or filled with mortar.
We adhere to the belief of "quality first, reputation first"; With the tenet of "customer first, serving the public", we welcome friends from all walks of life at home and abroad to visit and guide us and discuss cooperation matters. Anzhong Building Materials is willing to cooperate sincerely with all circles at home and abroad to seek common development, share gains and create a better living environment!
