The difficult process of Siemens Wincc 6.2 to Wincc 7.3
For an old project, the system adopts the Windows XP English version of Siemens industrial personal computer, and Wincc adopts the V6.2 version. With the continuous updating of the computer operating system, the new Wincc 7.3 sp1 can no longer be installed in Windows xp
So I had no choice but to replace the system and install it using the Windows 7 operating system. After the installation, I opened the 6.2 project, prompted the need for migration, and started the migration process after confirming
The migration process was smooth without any error. The whole process was completed in about 15 minutes. After the migration is completed, the project is also opened smoothly. Only after the editing screen window is opened, it is found that the fonts of the screen are all question marks. After the language is set to Chinese, only the fonts of the buttons can be displayed normally, and the others are all ""?? question mark
The following are the?? The attribute of the text. The text displays a question mark.
This is the attribute of the button. The button text displays normally
I really couldn't find the problem. I deleted the migrated program and replanted it again, but the problem still exists.
Fortunately, there is a virtual machine installed on the computer. Wincc 7.0 SP3 is installed in another Windows XP virtual machine. After the installation is successful, open the project. After the migration process, open the screen editor, and the language is set to Chinese. The font display is normal
I thought it was a font problem, so I copied the font in Windows XP to Windows 7, and then migrated it. The result is that after the screen editor is opened, the font is still displayed?? question mark. It seems that it is not a matter of font.
Then copy the project migrated from Windows XP to 7.0 to the Windows 7 system, open it with Wincc7.3 sp1, prompt for migration, and repeat the previous migration process.
This migration process is a bit long. It took about half an hour to complete the migration. After opening the project, you can enter the screen editing window. With a nervous mood, the success or failure depends on it. After entering the screen, you can still display the image?? The question mark found that the language was not changed to Chinese. After the change to Chinese, the text displayed normally, and a heart finally put down.
The following is the rendering of migration from Wincc7.0 SP3 to Wincc 7.3 SP1.
To sum up, if Wincc6.2 needs to be migrated to 7.3, it needs to migrate 6.2 to 7.0 first, and then to 7.3. It is recommended to install a virtual machine software on the computer, two virtual machines, one with Wincc7.0 and one with Wincc7.3
